Drum Heating Oven

Get a Price/Quote

Drum Heating Oven Specification

Power Source
Electric

Heating Capacity
2 Drums (each up to 200 L)

Condition
New

Heating Method
Hot Air Circulation

Control Mode
Digital PID Controller

Accuracy
1C

Type
Industrial Drum Heating Oven

Model
Custom

Internal Size
900 mm x 900 mm x 1500 mm

External Size
1220 mm x 1220 mm x 2130 mm

Volume
Approx. 1.2 m

Air Flow
Forced

Temperature Range
Ambient to 300C

Material
Mild Steel (Powder Coated)

Dimension (L*W*H)
1220 mm x 1220 mm x 2130 mm

Power
6 kW

Voltage
415V AC, 3 Phase

Surface Finish
Powder Coated

Ambient Operating Condition
Up to 45°C and 80% RH

Maximum Drum Diameter
600 mm

Compliance
CE Marked

Insulation Thickness
100 mm Mineral Wool

Number of Shelves
1 Removable Heavy Duty Shelf

Thermocouple
Type K

Chamber Lighting
Internal Heat Resistant Lamp

Timer Function
Programmable Digital Timer

Mobility
Mounted on Heavy Duty Lockable Wheels

Door Type
Front Hinged Double Door with Gasket

Safety Features
Over Temperature Protection, Emergency Stop

About Drum Heating Oven

Featured for its world-class engineering and enviable performance, this Industrial Drum Heating Oven is on offer with a clearance deal for new installations. With a lofty temperature range up to 300C, the oven ensures safe, precise heating for up to two 200L drums. Front hinged double doors with gaskets and 100mm mineral wool insulation ensure outstanding thermal efficiency. A programmable digital timer, over-temperature protection, and safety features deliver peace of mind. The oven is constructed from powder-coated mild steel and designed for heavy-duty use, boasting forced air flow and removable shelves. CE marked and manufactured in India for dealers, exporters, and industrial service providers.

Directions and Application Areas

For optimal results, position the Drum Heating Oven on a stable, level surface. Gently place the drums (up to 600 mm diameter) on the heavy-duty removable shelf inside the chamber. This oven is specifically designed for industrial settings, suitable for heating and processing chemicals, oils, and resins in metal drums. Application is ideal on drum exteriors in manufacturing plants, chemical processing sites, and warehouses where precise and even heating is required for efficient workflow.

Logistics and Export Specifications

Drum Heating Ovens are dispatched from renowned FOB ports across India, ensuring prompt delivery and handling for both domestic and global clients. Main domestic markets include major industrial hubs in India, while primary export markets extend to Europe, Southeast Asia, and the Middle East. Competitive outlay options are available for bulk orders. Coordinated dispatching processes ensure the oven's safe arrival, with robust packaging for assured quality upon delivery at your facility.

FAQ's of Drum Heating Oven:

Q: How does the Drum Heating Oven ensure safe operation during use?

A: The oven includes over-temperature protection, an emergency stop, and programmable digital controls that help prevent overheating and ensure operator safety at all times.

Q: What is the recommended process for loading drums into the oven?

A: Load up to two 200L drums carefully onto the removable heavy-duty shelf. Ensure they are spaced apart for uniform hot air circulation before setting the timer and temperature controls.

Q: Where can the Drum Heating Oven be installed for optimal effectiveness?

A: It is ideally installed in well-ventilated industrial environments such as factories, chemical plants, or warehouse facilities. The unit's lockable wheels offer mobility for flexible site placement.

Q: When is the best time to use the programmable timer feature?

A: The programmable digital timer is optimal for processes requiring precise heating intervals, enabling automated operation for batch production cycles or time-sensitive heating tasks.

Q: What are the key benefits of using a front-hinged double door with gasket insulation?

A: This design maximizes thermal efficiency, minimizes heat loss, and ensures consistent temperature control, yielding better energy savings and product reliability during long heating cycles.
