Automatic Conveyorised Powder Coating Plant

Get a Price/Quote

Automatic Conveyorised Powder Coating Plant Specification

Product Type
Automatic Conveyorised Powder Coating Plant

General Use
Industrial automatic powder coating of metal components

Material
Mild Steel (Structure), High Quality Insulation Materials

Type
Automatic Conveyorized Plant

Weight (kg)
Custom as per plant size, approx. 1500-3000 kg

Coating Speed
Variable, typically 1-3 m/min

Coating Head
Automatic Reciprocal Spray Guns

Coating Width
Up to 1200 mm as per job

Coating Material
Electrostatic powder (polyester, epoxy, hybrid, etc.)

Computerized
Yes

Automatic
Yes

Control System
PLC Based Control Panel

Power Source
Electric

Power Consumption
Approx. 25-45 kW (depends on plant size)

Heating System
Electric Heating (Oven) / Gas Fired on request

Drive Type
Chain Conveyor Drive

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
Customized as per plant layout, example: 20000 x 3500 x 3500 mm

Feature
Fully automatic operation, uniform powder application, energy efficient

Color
As per requirement (usually industrial grey/orange)

Loading/Unloading
Manual or Robotic Integration Available

Curing Oven Type
Tunnel type with Air Circulation

Max Component Size
Custom (e.g., up to 2.5m length)

Production Capacity
Up to 300 components/hour (varies on size & configuration)

Conveyor Type
Overhead Continuous Conveyor

Filtration System
Cartridge/Bag Filter for Powder Recovery

Painting Technology
Electrostatic Powder Spraying

Oven Temperature Range
Up to 250°C

Powder Recovery
Automatic Powder Reclaim and Recycling System

Surface Preparation
Optional Pre-Treatment Plant (7/9 tank process)

Operating Environment
Indoor, Ambient 10-40°C

Installation & Commissioning
On-site service provided

Safety
Interlocks, Emergency Shutdown, Exhaust Controls

About Automatic Conveyorised Powder Coating Plant

Experience world-class performance and excellent value with our Automatic Conveyorised Powder Coating Plant, now available at a reduced price with a special price cut offer. This popular system features a gilt-edged overhead continuous conveyor, supporting custom component sizes up to 2.5m and fast production rates of up to 300 components per hour. Benefit from superior tunnel-type ovens with air circulation, advanced cartridge/bag filtration for powder recovery, and optional surface pre-treatment. Fully automatic operation, energy efficiency, and safety interlocks deliver optimal, uniform results every time. Ideal for fabricators and manufacturers seeking reliable, high-quality powder coating solutions in India.

Versatile Applications of Automatic Conveyorised Powder Coating Plant

This plant is widely used across metalworking industries for coating steel, aluminum, and similar materials. Beyond typical industrial fabrication, it's suitable for automotive, furniture, electrical enclosures, and general engineering component finishing. Its flexibility supports various plant applications, including corrosion protection, aesthetic enhancement, and high-volume production. Whether for OEM fabrication, contract manufacturing, or R&D environments, this system is engineered for reliable, gilt-edged results in diverse settings.

Packaging, Delivery, and Shipping Details

Each Automatic Conveyorised Powder Coating Plant is carefully packaged for safe transit and timely installation. We ensure quick dispatch following receipt of the purchase order and proposal amount confirmation. Delivery times are typically coordinated to meet customer requirements and project schedules. Our standard FOB port for export is located in India, supporting seamless global logistics for dealers, distributors, and direct buyers. Comprehensive support and installation services are included with every shipment.

FAQ's of Automatic Conveyorised Powder Coating Plant:

Q: How does the Automatic Conveyorised Powder Coating Plant operate?

A: The plant utilizes an overhead continuous chain conveyor for smooth component movement. Electrostatic spray guns ensure uniform coating, while a tunnel oven cures the finish. Operations are fully automatic and PLC-controlled for consistency and efficiency.

Q: What types of materials and components can be processed?

A: This system handles mild steel, aluminum, and various metal components, up to 2.5 meters in length and 1200 mm in width. It's ideal for industry sectors like automotive, furniture, and electrical fabrication.

Q: Where can the Automatic Conveyorised Powder Coating Plant be installed?

A: The plant is best suited for indoor industrial environments with ambient temperatures between 10C and 40C. Installation and commissioning are carried out on-site, with plant dimensions customized as per your site layout.

Q: What is the benefit of the automatic powder reclaim and recycling system?

A: The integrated cartridge or bag filter recovery system captures overspray for recycling, reducing powder wastage and enhancing cost savings, making the coating process both efficient and environmentally responsible.

Q: How long does delivery and installation typically take?

A: Quick dispatch is available upon purchase order and deposit. Exact delivery and setup timelines depend on plant size and customization, but our team coordinates closely with clients to ensure prompt, reliable installation.
